【 About this project 】
【Notice】
1. Please contact us if you need other specifications.
2. Payment terms: Samples 100% payment in advance, bulk order 30% deposit, 70% payment before shipment. Sample order accepted.
3. Sample delivery time is 7 working days after payment is received for bulk orders, and shipping time is negotiated.
4. The shipping fees should be covered by buyers, please contact us for details.
5. Warranty: One year.
【Advantages】
Compact Design
The BVS-C0B is a highly efficient mini desktop computer, measuring only 99.50 x 99.50 x 35mm. Its small form factor makes it an ideal choice for environments with limited space, such as retail displays, kiosks, and home offices.
Powerful Performance
Powered by Alder Lake-N N100/N150, this mini desktop PC can reach speeds up to 3.6GHz, providing responsive performance for everyday tasks. The system supports up to 16GB of LPDDR4 RAM, making it suitable for multitasking and running lightweight applications efficiently.
Customizable Storage
With multiple storage options including M.2 NVME SSD (up to 2TB) and 2.5" SATA SSD (up to 2TB), the BVS-3V provides high-speed data access and ample storage space for various applications. The flexible storage options allow users to tailor the system for specific needs, from data-intensive tasks to high-performance applications.
Dual Display Support
The BVS-C0B mini PC supports HDMI+DP outputs, enabling dual-display setups for enhanced productivity or digital signage. Whether you need a multi-screen setup in an office, retail space, or for industrial applications, the dual-display capability is a valuable feature.
Reliability and Security
With FTPM support, auto power-on, and real-time clock (RTC) functionality, the BVS-C0B ensures secure booting and reliable performance in mission-critical environments. These features are essential for use in industrial control systems, digital kiosks, and other applications that require continuous operation.
【Parameter】
|
Product Model (Subject)：BVS-C0B |
|||
|
Product Appearance |
|||
|
Type |
Spec. |
Standard Configuration |
Optional |
|
Product |
Product Type |
MINI PC, Ad Terminal Box |
|
|
Dimension |
99.50 x 99.50 x 35mm |
|
|
|
Case Material |
Plastic |
|
|
|
Weight |
NA |
|
|
|
System Hardware Configuration |
|||
|
Type |
Spec. |
Description |
Optional |
|
CPU |
Model |
Alder Lake-N N100(N150) |
Optional |
|
Max. Turbo Speed |
3.6GHz(N150),3.4Ghz(N100) |
|
|
|
Power Consumption |
6W |
|
|
|
Memory |
Model |
LPDDR4 |
|
|
Capacity |
2x LPDDR4 Max 16GB on Board |
Optional |
|
|
Storage |
EMMC |
/ |
|
|
SSD |
M.2 2242/2280 NFGG/NVME(customized） ，Max 2TB |
Optional |
|
|
2.5'' SSD |
2.5'' SATA，Max 2TB |
Optional |
|
|
TF Card |
No Supporting |
|
|
|
RTC |
BIOS |
Real-time Clock, Time Boot |
|
|
Auto Power On |
BIOS |
Support auto power on after electrified |
|
|
Diskless Network |
BIOS |
Support uefi/Legacy Diskless Switch On |
|
|
TPM |
CPU integratesTPM |
Support TPM 2.0 |
|
|
Triple Display |
Video Output |
1xHDMI 2.0+1xDP Triple Display |
|
|
LED |
State |
Blue light- Swith on |
|
|
Internet Connection |
|||
|
Type |
Spec. |
Description |
Optional |
|
WIFI |
Model |
on board (wifi5/6) |
Optional |
|
Protocol |
IEEE 802.11 a, b/g, n, ac，ax |
|
|
|
Bluetooth |
Model |
usb |
Optional |
|
Protocol |
Support Bluetooth 4.2/5.2 |
|
|
|
3G |
Built-in |
No |
|
|
4G |
Built-in |
No |
|
|
Ethernet |
LAN1 |
10M/100M/1000M Self-adaption |
|
|
I/O |
|||
|
Type |
Spec. |
Description |
Optional |
|
USB |
USB2.0 |
USB2.0 Type-A*2 480Mbps |
|
|
USB |
USB3.0 |
USB3.0 Type-A*2 5Gpbs |
|
|
TF |
Expansion Memory |
No |
|
|
HDMI |
AV Output |
HDMI 2.0 Type A x2 |
|
|
DP |
Video Output |
DP x1 |
|
|
RJ45 |
Gigabyte Ethernet |
10/100/1000M*1 |
|
|
Uart |
Data Transmission |
No |
|
|
POWER |
Power Button |
x1 |
|
|
DC IN |
Power Supply Input |
5.5*2.1mm DC Jack x1 |
|
|
Audio-in/out |
Audio-in/out |
3.5mm Phone Jack x1 （2 in 1） |
|
|
Antenna1 |
FPC Antenna |
WiFi 2.4+5G+BT *1 |
|
|
Antenna2 |
FPC Antenna |
WIFI 5.0 |
|
|
SIM |
Micro SIM |
No |
|
|
Software Configuration |
|||
|
Type |
Spec. |
Description |
Optional |
|
OS |
Version |
Windows 11/ubuntu |
|
|
Environment |
|||
|
Type |
Spec. |
Description |
Optional |
|
Environment |
Working Temperature |
0~40℃ |
|
|
Memory Temperature |
-20~60℃ |
|
|
|
Humidity |
90% @ 40 °C (No Condensation) |
|
|
|
Accessory |
|||
|
Type |
Spec. |
Description |
Optional |
|
Power Supply |
Vesa |
Input 100~240V 50/60Hz Output 12V/2.5A, 5.5*2.1mm |
|
|
IR Remote Control |
No |
|
|
【Application】
Retail Environments
In retail, the BVS-C0B mini desktop PC powers interactive kiosks, point-of-sale systems, and digital signage. Its small size allows it to be easily mounted behind displays or placed in tight spaces, while the dual HDMI outputs support multiple screens for advertising or customer interaction.
Industrial Automation
This mini desktop computer is ideal for use in factory automation and control systems. With its Alder Lake-N processor, flexible storage options, and dual LAN ports, the BVS-C0B can be seamlessly integrated into production lines for real-time monitoring, data logging, and equipment control.
Smart Offices
For smart office setups, the BVS-C0B mini desktop PC can power interactive whiteboards, video conferencing systems, and digital signage. Its compact design, dual-display capability, and reliable performance make it an excellent choice for businesses looking to streamline operations and enhance collaboration in the workplace.
Home Automation
The mini desktop PC is also perfect for home automation and smart home hubs. It can control lighting, security systems, and other IoT devices, providing a reliable interface for managing smart home environments, all within a compact and energy-efficient form factor.
Education and E-learning
In educational settings, the BVS-C0B mini PC can support interactive learning tools, smart classrooms, and e-learning platforms. Its small size and powerful performance allow it to run educational software and online learning platforms while saving valuable space in classrooms and training rooms.
